| Component | Specification |
|---|---|
| Booth Cabin Panel | High gloss white rock wool panel, thickness 75mm with edges. Color steel plate thickness 0.476mm |
| Front Door/Safety Door | Four sheet metal front doors (4×3.8m) and 2 safety doors (2000×800mm) |
| Top Lighting | 16 sets of LED lights, each set 4×18W |
| Middle Lighting | 16 sets of LED lights, each set 4×18W |
| Ceiling Filter | 12 sets of grill type net supporting installation |
| Intake Fan | 2 units of European type fan with capacity of 60000m³/h (two sets of intake fans) |
| Exhaust Fan | 2 units of European type fan with capacity of 60000m³/h (two sets of exhaust fans) |
| VCD Damper | 2 units |
| Load Air Velocity | 0.25-0.35 m/s |
| Exhaust Duct | 4 meters of straight duct and 1 piece of 90° bend and 1 piece of 45° bend (2 sets) |
| Heating Method | RIELLO brand RG5S diesel burner, cycle heating (2 sets) |
| Max. Working Temperature | 80℃ |
| Constant Temp. Spray Painting | Constant Temperature Operation |
| Control Panel | Made by quality components with the functions of overload, overheat and phase lack protection |
| Functions | Spray, Bake, Lighting and Emergency Stop |
